Neera 1-Handle Culinary Pull-Down Kitchen Faucet parts
16 part numbers on Pfister’s parts diagram. 15 in our catalog, the rest we order in.
Model numbers: LG529-NECBLG529-NECBGLG529-NECCLG529-NECS
Neera 1-Handle Culinary Pull-Down Kitchen Faucet exploded diagram
Tap a part number to see the part, its price and fit. Blue parts are in our catalog; gray ones we order in.
950-345
Verified fit On Pfister’s Neera 1-Handle Culinary Pull-Down Kitchen Faucet parts diagram
Neera 1-Handle Culinary Pull-Down Kitchen Faucet parts list
- 940-6025 finishes
Neera Spg Spt Assy W/arm-slv Nec Nec
Verified fit On Pfister’s parts diagram for this model
$158.95 - 940-6034 finishes
Neera Hdl W/dome Cap-scr 529 Ne Ne
Verified fit On Pfister’s parts diagram for this model
$28.05 Verified fit On Pfister’s parts diagram for this model
$5.95Cart 25mm W/nut-remvl Tool Tool
Verified fit On Pfister’s parts diagram for this model
$34.85Verified fit On Pfister’s parts diagram for this model
Verified fit On Pfister’s parts diagram for this model
$20.40- 950-4045 finishes
Sprayhead for Kwan Neera & Raya Culinary Faucet
Verified fit On Pfister’s parts diagram for this model
$41.65 - 951-3432 finishes
Neera P/o Hs W/q/c Ne Bk Ne Bk
Verified fit On Pfister’s parts diagram for this model
$43.35 Verified fit On Pfister’s parts diagram for this model
$6.80- 974-3846 finishes
Raya Base Rng W/putty Plt 1h 529 Ry 529 Ry
Verified fit On Pfister’s parts diagram for this model
$10.20 - 941-0859 finishes
Verified fit On Pfister’s parts diagram for this model
$11.90 Verified fit On Pfister’s parts diagram for this model
$9.35- 961-2016 finishes
Verified fit On Pfister’s parts diagram for this model
$44.20 Verified fit On Pfister’s parts diagram for this model
$5.95Kitchen and Lavatory Installation Tool
Verified fit On Pfister’s parts diagram for this model
$13.60Lock Nut and Washer For Elevate 529 Series Faucet, metal
Verified fit On Pfister’s parts diagram for this model
$15.30
About the Pfister Neera 1-Handle Culinary Pull-Down Kitchen Faucet
If there’s one faucet that’s prepared to bring out your inner chef at the drop of an impromptu dinner party, Neera is it. Soft, clean, transitional lines look beautiful in repose while the culinary option hints contemporary flair. This powerhouse is packed with features for chefs and foodies alike. Available in the most current finishes, Neera’s all the inspiration you need to dive into a new cook
- Meets ADA/ANSI A117.1 requirements, ensuring accessibility to all disabled persons
- Pforever Seal™ features an advanced ceramic disc valve technology with a never-leak guarantee
- Complies with Federal and State safe drinking water legislation.
- Optional decorative deck plate sold separately
- 1-hole installation
- High arc spout for added clearance and reach
- Pull-down spray head, select from 3 water settings conveniently in the palm of your hand
- Advanced spray head docking system ensures a secure, tight connection to the faucet spout
- Wipe Clean Nozzles allows you to wipe away mineral deposits with the swipe of a finger
- Elegant forward handle design underscores ergonomic function and helps where space behind the faucet is limited
| GPM Flow Rate | 1.8 |
|---|---|
| # of Handles | 1 |
| Total Spout Height | 18-5/8 |
| Deck To Aerator Height | 7-15/32 |
| Deckplate Included | No |
| Max Deck Thickness | 3 |
| Soap Dispenser | No |
| Spray Functions | Spray and Stream with Pause Control |
| Pull-Out/Down Hose Length | 12.5 |
| Pull-Out/Down Hose Material | Braided Nylon |
| Faucet Arc Type | High-Arc |
| Configurations | 1-Hole |
Neera 1-Handle Culinary Pull-Down Kitchen Faucet parts questions
What cartridge does the Pfister Neera 1-Handle Culinary Pull-Down Kitchen Faucet (LG529-NECB) use?
Pfister's parts diagram for the LG529-NECB lists 974-074 (Ceramic Disc Cartridge).
How many replacement parts are on the LG529-NECB diagram?
Pfister's parts diagram for the Neera 1-Handle Culinary Pull-Down Kitchen Faucet shows 16 part numbers, including handles, trim and hardware. Tap any part on our interactive diagram to see price and finish.
Which model numbers are covered on this page?
LG529-NECB, LG529-NECBG, LG529-NECC, LG529-NECS. The letters at the end of a Pfister model number are the finish.
