Brookwood 1-Handle Kitchen Faucet parts
24 part numbers on Pfister’s parts diagram. 18 in our catalog, the rest we order in.
Model numbers: LF-034-3ALCLF-034-3ALSLF-034-3ALY
Brookwood 1-Handle Kitchen Faucet exploded diagram
Tap a part number to see the part, its price and fit. Blue parts are in our catalog; gray ones we order in.
931-053
Verified fit On Pfister’s Brookwood 1-Handle Kitchen Faucet parts diagram
Brookwood 1-Handle Kitchen Faucet parts list
- 941-9003 finishes
Verified fit On Pfister’s parts diagram for this model
$7.65 Verified fit On Pfister’s parts diagram for this model
Verified fit On Pfister’s parts diagram for this model
Verified fit On Pfister’s parts diagram for this model
$14.45- 940-0953 finishes
Verified fit On Pfister’s parts diagram for this model
$32.30 Verified fit On Pfister’s parts diagram for this model
$9.35- 941-4623 finishes
Brookwood Aer Jr W/hsg-wshr 34 Bw
Verified fit On Pfister’s parts diagram for this model
$11.05 Verified fit On Pfister’s parts diagram for this model
$20.40- 950-1183 finishes
Verified fit On Pfister’s parts diagram for this model
$14.45 - 961-0883 finishes
DKPLT SA 034 BW CR Polished Chrome
Verified fit On Pfister’s parts diagram for this model
$91.80 Verified fit On Pfister’s parts diagram for this model
$5.95- 951-0783 finishes
Verified fit On Pfister’s parts diagram for this model
$90.95 Verified fit On Pfister’s parts diagram for this model
$11.90Verified fit On Pfister’s parts diagram for this model
- 949-0522 finishes
Wayland Friction Washer Blk - Black
Verified fit On Pfister’s parts diagram for this model
$5.95 - 931-0463 finishes
Ktch Po Dkplt S/A Sgl Hle Chrome
Verified fit On Pfister’s parts diagram for this model
$27.20 - 931-0523 finishes
Brookwood 34 Series Spout Escutcheon less Side Spray Hole
Verified fit On Pfister’s parts diagram for this model
$112.20 Verified fit On Pfister’s parts diagram for this model
$5.95- 931-0533 finishes
Verified fit On Pfister’s parts diagram for this model
$31.45 Verified fit On Pfister’s parts diagram for this model
Verified fit On Pfister’s parts diagram for this model
$7.65Verified fit On Pfister’s parts diagram for this model
Verified fit On Pfister’s parts diagram for this model
$41.65Verified fit On Pfister’s parts diagram for this model
About the Pfister Brookwood 1-Handle Kitchen Faucet
Inspired by a classical style and infused with contemporary lines, the Brookwood collection provides a decorative accent for a variety of settings. With a base design that mimics the beauty of an Old English lamppost, the Brookwood Collection is available in a variety of finishes to light up any modern kitchen.
- Meets ADA/ANSI A117.1 requirements, ensuring accessibility to all disabled persons
- Pforever Seal™ features an advanced ceramic disc valve technology with a never-leak guarantee
- Complies with Federal and State safe drinking water legislation.
- Includes coordinating, decorative side spray
- Spout swivels for added maneuverability
- Pfast Connect™ technology securely connects water supply lines with a quick click
- High arc spout for added clearance and reach
- Rated to meet or exceed CALGreen criteria, which helps to conserve water in the average home by at least 20 percent
- Pforever Seal®
| GPM Flow Rate | 1.8 |
|---|---|
| # of Handles | 1 |
| Total Spout Height | 7-3/8 |
| Deck To Aerator Height | 4-11/16 |
| Deckplate Included | N/A |
| Max Deck Thickness | 2-15/32 |
| Soap Dispenser | No |
| Type Side Spray | Side Spray in coordinating finish |
| Faucet Arc Type | High-Arc |
| Configurations | 2-Hole 4-Hole |
Brookwood 1-Handle Kitchen Faucet parts questions
What cartridge does the Pfister Brookwood 1-Handle Kitchen Faucet (LF-034-3ALC) use?
Pfister's parts diagram for the LF-034-3ALC lists 962-075 (Cartridge Retainer Nut), 974-074 (Ceramic Disc Cartridge).
How many replacement parts are on the LF-034-3ALC diagram?
Pfister's parts diagram for the Brookwood 1-Handle Kitchen Faucet shows 24 part numbers, including trim and hardware. Tap any part on our interactive diagram to see price and finish.
Which model numbers are covered on this page?
LF-034-3ALC, LF-034-3ALS, LF-034-3ALY. The letters at the end of a Pfister model number are the finish.
