Ametrine 2-Handle 8" Widespread Bathroom Faucet parts diagram
Pfister · Bathroom Faucets / Widespread

Ametrine 2-Handle 8" Widespread Bathroom Faucet parts

14 part numbers on Pfister’s parts diagram. 10 in our catalog, the rest we order in.

Model numbers: HHL-49-AMTCBGHHL-49-AMTCCHHL-49-AMTCDHHL-49-AMTCKHHL-49-AMTCSDBHHL-49-AMTLBGHHL-49-AMTLCHHL-49-AMTLDHHL-49-AMTLKHHL-49-AMTLSDBHHL-49-AMTRBGHHL-49-AMTRCHHL-49-AMTRDHHL-49-AMTRKHHL-49-AMTRSDBLG49-AMT1BGLG49-AMT1CLG49-AMT1DLG49-AMT1KLG49-AMT1SDB

Open the diagramPfister’s PDF

Ametrine 2-Handle 8" Widespread Bathroom Faucet exploded diagram

Tap a part number to see the part, its price and fit. Blue parts are in our catalog; gray ones we order in.

Ametrine 2-Handle 8" Widespread Bathroom Faucet exploded parts diagram

Tap any part number on the diagram to see what it is, whether we stock it, and add it to your cart.

Ametrine 2-Handle 8" Widespread Bathroom Faucet parts list

About the Pfister Ametrine 2-Handle 8" Widespread Bathroom Faucet

  • Water flows at 1.2 gallons per minute, creating a strong, consistent flow while minimizing water waste
  • UltraSeal™ features an all metal 1/4 turn cartridge for superior durability and handle feel
  • Handles sold separately; order HHL-49-AMTLX, HHL-49-AMTCX, or HHL-49-AMTRX seperately
  • Fixed hubs for smooth handle rotation
  • Adjustable installation; designed to fit 8”-15” adjustable widespread configurations for versatile placement
  • Features an all metal Push & Seal drain assembly
  • Pfast Connect™ reduces installation time and guarantees a secure connection to water supply lines
  • All model numbers beginning with LG, G, and GT meet the requirements of the California Energy Commission
  • IAPMO certified to all applicable standards within the Uniform Plumbing Code (cUPC)
  • Lifetime Warranty
Specifications
GPM Flow Rate1.2
Total Spout Height8-1/8
Deck To Aerator Height5-1/8
Drain AssemblyAmerican All Metal Push & Seal
Max Deck Thickness3
Configurations3-Hole

Ametrine 2-Handle 8" Widespread Bathroom Faucet parts questions

What cartridge does the Pfister Ametrine 2-Handle 8" Widespread Bathroom Faucet (HHL-49-AMTCBG) use?

Pfister's parts diagram for the HHL-49-AMTCBG does not list a separate cartridge. The valve may be sold separately; check the valve model on the diagram or ask our counter.

How many replacement parts are on the HHL-49-AMTCBG diagram?

Pfister's parts diagram for the Ametrine 2-Handle 8" Widespread Bathroom Faucet shows 14 part numbers, including trim and hardware. Tap any part on our interactive diagram to see price and finish.

Which model numbers are covered on this page?

HHL-49-AMTCBG, HHL-49-AMTCC, HHL-49-AMTCD, HHL-49-AMTCK, HHL-49-AMTCSDB, HHL-49-AMTLBG, HHL-49-AMTLC, HHL-49-AMTLD, HHL-49-AMTLK, HHL-49-AMTLSDB, HHL-49-AMTRBG, HHL-49-AMTRC, HHL-49-AMTRD, HHL-49-AMTRK, HHL-49-AMTRSDB, LG49-AMT1BG, LG49-AMT1C, LG49-AMT1D, LG49-AMT1K, LG49-AMT1SDB. The letters at the end of a Pfister model number are the finish.
