Port Haven 1-Handle Bar & Prep Faucet exploded diagram
Tap a part number to see the part, its price and fit. Blue parts are in our catalog; gray ones we order in.
920-264
Verified fit On Pfister’s Port Haven 1-Handle Bar & Prep Faucet parts diagram
Port Haven 1-Handle Bar & Prep Faucet parts list
- 920-2645 finishes
Verified fit On Pfister’s parts diagram for this model
$33.15 Verified fit On Pfister’s parts diagram for this model
$20.40Verified fit On Pfister’s parts diagram for this model
$9.35- 940-7425 finishes
Verified fit On Pfister’s parts diagram for this model
$29.75 Verified fit On Pfister’s parts diagram for this model
Lock Nut and Washer For Elevate 529 Series Faucet, metal
Verified fit On Pfister’s parts diagram for this model
$15.30- 961-2357 finishes
Tenet Dkplt W/putty Plt-foam 42 Tnt
Verified fit On Pfister’s parts diagram for this model
$26.35
About the Pfister Port Haven 1-Handle Bar & Prep Faucet
Whether you’re feeding four or forty, do it with flair. Industrial design gives the Port Haven collection just enough edge to offset the oh-so-elegant, statuesque faucets that make a statement in your kitchen without ever uttering a word. These faucets are anything but ordinary. Keeping with the theme of popular trends, Port Haven thrives in modern rustic, modern industrial and eclectic traditiona
- 1-hole installation
- High arc spout for added clearance and reach
- Elegant forward handle design underscores ergonomic function and helps where space behind the faucet is limited
- Pfast Connect™ technology securely connects water supply lines with a quick click
- Pforever Seal™ features an advanced ceramic disc valve technology with a never-leak guarantee
- Spout swivels for added maneuverability
- 36 in. Integrated Flexible Nylon Supply Lines with 3/8 in. connection
- TiteSeal™ Mounting Technology eliminates the need for putty or silicone and simplifies installation
- Optional decorative deck plate sold separately
- Optional deck plate Available, order 961-235*
| GPM Flow Rate | 1.8 |
|---|---|
| # of Handles | 1 |
| Total Spout Height | 12-7/16 |
| Deck To Aerator Height | 7-13/16 |
| Deckplate Included | No |
| Max Deck Thickness | 3 |
| Soap Dispenser | No |
| Supply Lines | Nylon Flex-Line |
| Faucet Arc Type | High-Arc |
Port Haven 1-Handle Bar & Prep Faucet parts questions
What cartridge does the Pfister Port Haven 1-Handle Bar & Prep Faucet (GT72-TDBG) use?
Pfister's parts diagram for the GT72-TDBG lists 974-074 (Ceramic Disc Cartridge), 962-075 (Cartridge Retainer Nut).
How many replacement parts are on the GT72-TDBG diagram?
Pfister's parts diagram for the Port Haven 1-Handle Bar & Prep Faucet shows 7 part numbers, including trim and hardware. Tap any part on our interactive diagram to see price and finish.
Which model numbers are covered on this page?
GT72-TDBG, GT72-TDC, GT72-TDD, GT72-TDS, GT72-TDSDB, GT72-TDY. The letters at the end of a Pfister model number are the finish.
