Contempra Single Control Vessel Bathroom Faucet parts
12 part numbers on Pfister’s parts diagram. 10 in our catalog, the rest we order in.
Model numbers: GT40-NC00GT40-NK00LG40-NC00
Contempra Single Control Vessel Bathroom Faucet exploded diagram
Tap a part number to see the part, its price and fit. Blue parts are in our catalog; gray ones we order in.
Tap any part number on the diagram to see what it is, whether we stock it, and add it to your cart.
Contempra Single Control Vessel Bathroom Faucet parts list
- 940-8344 finishes
Verified fit On Pfister’s parts diagram for this model
$44.20 Verified fit On Pfister’s parts diagram for this model
- 962-0593 finishes
Contempra Ins Plstc 40/42 Cn Bk - Black
Verified fit On Pfister’s parts diagram for this model
$5.95 - 941-2124 finishes
PLG HDL 4042 CN CR Polished Chrome
Verified fit On Pfister’s parts diagram for this model
$6.80 Verified fit On Pfister’s parts diagram for this model
$6.80- 961-0994 finishes
Verified fit On Pfister’s parts diagram for this model
$95.20 Verified fit On Pfister’s parts diagram for this model
Verified fit On Pfister’s parts diagram for this model
$9.35Contempra Aer S/a 40/42 Cn Bk Cn Bk
Verified fit On Pfister’s parts diagram for this model
$15.30- 961-0944 finishes
Contempra Pty Plt- Flg 1h 40/42 Cn
Verified fit On Pfister’s parts diagram for this model
$20.40 Verified fit On Pfister’s parts diagram for this model
$20.40Verified fit On Pfister’s parts diagram for this model
$7.65
About the Pfister Contempra Single Control Vessel Bathroom Faucet
If a sleek and sophisticated design is what you are looking for, the Contempra family is the perfect option. This collection of bath products incorporates clean contemporary lines for a very modern presence. With a complete collection to suit your design vision, Contempra is the perfect choice for any bath.
- Meets ADA/ANSI A117.1 requirements, ensuring accessibility to all disabled persons
- Pforever Seal™ features an advanced ceramic disc valve technology with a never-leak guarantee
- Complies with Federal and State safe drinking water legislation.
- Meets or exceeds EPA WaterSense Standards, which reduces water consumption by 30% and helps average households save up to $200 in their annual water bill
- Faucet mounted on sink deck or countertop
- Includes single post mounting ring
- Includes metal supply nuts
- Includes valve and cartridge
- 1-hole installation
- Drain assembly purchased separately
| GPM Flow Rate | 1.5 |
|---|---|
| # of Handles | 1 |
| Total Spout Height | 11-3/4 |
| Deck To Aerator Height | 8-1/2 |
| Deckplate Included | N/A |
| Drain Assembly | Less drain assembly |
| Max Deck Thickness | 3 |
| Configurations | 1-Hole |
Contempra Single Control Vessel Bathroom Faucet parts questions
What cartridge does the Pfister Contempra Single Control Vessel Bathroom Faucet (GT40-NC00) use?
Pfister's parts diagram for the GT40-NC00 lists 962-075 (Cartridge Retainer Nut), 974-074 (Ceramic Disc Cartridge).
How many replacement parts are on the GT40-NC00 diagram?
Pfister's parts diagram for the Contempra Single Control Vessel Bathroom Faucet shows 12 part numbers, including handles, trim and hardware. Tap any part on our interactive diagram to see price and finish.
Which model numbers are covered on this page?
GT40-NC00, GT40-NK00, LG40-NC00. The letters at the end of a Pfister model number are the finish.
