Sonterra 2-Handle Kitchen Faucet parts
15 part numbers on Pfister’s parts diagram. 14 in our catalog, the rest we order in.
Model numbers: F-036-4SNC
Sonterra 2-Handle Kitchen Faucet exploded diagram
Tap a part number to see the part, its price and fit. Blue parts are in our catalog; gray ones we order in.
940-216
Verified fit On Pfister’s Sonterra 2-Handle Kitchen Faucet parts diagram
Sonterra 2-Handle Kitchen Faucet parts list
HDL Index BTN CR Polished Chrome
Verified fit On Pfister’s parts diagram for this model
$5.95Verified fit On Pfister’s parts diagram for this model
$55.25Verified fit On Pfister’s parts diagram for this model
$7.65Verified fit On Pfister’s parts diagram for this model
$57.80Verified fit On Pfister’s parts diagram for this model
$9.35Washer for Shear Valve Cartridge Retainer Nut
Verified fit On Pfister’s parts diagram for this model
$5.95Verified fit On Pfister’s parts diagram for this model
$7.65Shear Valve With Seat and Springs
Verified fit On Pfister’s parts diagram for this model
$9.35Verified fit On Pfister’s parts diagram for this model
$45.05AER SA 036 SON CR Polished Chrome
Verified fit On Pfister’s parts diagram for this model
$32.30Verified fit On Pfister’s parts diagram for this model
$5.95Verified fit On Pfister’s parts diagram for this model
O-Ring and Clips for Bathroom Faucet
Verified fit On Pfister’s parts diagram for this model
$3.40Pfirst Series Putty Plt G136-5 Bk A - Black
Verified fit On Pfister’s parts diagram for this model
$6.80Verified fit On Pfister’s parts diagram for this model
$5.95
About the Pfister Sonterra 2-Handle Kitchen Faucet
Sonterra's intricate curves, decorative high-arc spout, and classic styling accent the home with timeless sophistication.
- Meets ADA/ANSI A117.1 requirements, ensuring accessibility to all disabled persons
- Pforever Seal™ features an advanced ceramic disc valve technology with a never-leak guarantee
- Complies with Federal and State safe drinking water legislation.
- Includes coordinating, decorative side spray
- Pfast Connect™ technology securely connects water supply lines with a quick click
- Spout swivels 360 degrees for maximum maneuverability
- High arc spout for added clearance and reach
- 360 Degree Swivel
- MultiMount
- Pfast Connect Kitchen
| GPM Flow Rate | 1.8 |
|---|---|
| # of Handles | 2 |
| Total Spout Height | 11-13/32 |
| Deck To Aerator Height | 6-11/32 |
| Max Deck Thickness | 1-3/4 |
| Soap Dispenser | No |
| Type Side Spray | Side Spray in coordinating finish |
| Kitchen Faucet Hose Length | 47.625 |
| Faucet Arc Type | High-Arc |
| Configurations | 3-Hole 4-Hole |
Sonterra 2-Handle Kitchen Faucet parts questions
What cartridge does the Pfister Sonterra 2-Handle Kitchen Faucet (F-036-4SNC) use?
Pfister's parts diagram for the F-036-4SNC lists 949-057 (Washer for Shear Valve Cartridge Retainer Nut), 974-098 (Shear Valve With Seat and Springs), 974-011 (Shear Valve Seat).
How many replacement parts are on the F-036-4SNC diagram?
Pfister's parts diagram for the Sonterra 2-Handle Kitchen Faucet shows 15 part numbers, including trim and hardware. Tap any part on our interactive diagram to see price and finish.
Which model numbers are covered on this page?
F-036-4SNC. The letters at the end of a Pfister model number are the finish.
