Three-Handle 5-Hole Wall Mount Tub and Shower Faucet
Kingston Brass · Tub and Shower Faucets

Kingston Brass Legacy KB6230LL parts

Three-Handle 5-Hole Wall Mount Tub and Shower Faucet. One parts diagram covers all 5 finishes of this model.

Model numbers: KB6230LLKB6231LLKB6232LLKB6237LLKB6238LL

Open the diagramKingston’s PDF

Legacy KB6230LL exploded diagram

Tap a part number to see the part, its price and fit. Blue parts are in our catalog; gray ones we order in.

Legacy KB6230LL exploded parts diagram

Tap any part number on the diagram to see what it is, whether we stock it, and add it to your cart.

Need a part that isn’t listed?

Kingston numbers the parts on its diagrams without part numbers. Tap the number on the diagram, or send us the number with your model and finish, and we’ll look it up with Kingston and send a price.

Request a part from this diagram

Legacy KB6230LL parts questions

Which Kingston Brass models does this Legacy parts diagram cover?

KB6230LL, KB6231LL, KB6232LL, KB6237LL, KB6238LL. They are the same three-handle 5-hole wall mount tub and shower faucet in different finishes, so they share one parts diagram.

What finishes does the Kingston Brass KB6230LL come in?

Matte Black (KB6230LL), Polished Chrome (KB6231LL), Polished Brass (KB6232LL), Brushed Brass (KB6237LL), Brushed Nickel (KB6238LL).

What replacement handles fit the KB6230LL?

We don't list a matching handle for this model online. Send us the model number and finish and we'll order it from Kingston.

How do I order a part from the KB623xLL diagram?

Kingston numbers the parts on this diagram (24 parts) without part numbers. Tap the number and send it with your model and finish; our counter looks it up with Kingston and sends a price.

Legacy KB623xLL in every finish
