Kingston Brass KB1970AX exploded diagram
Tap a part number to see the part, its price and fit. Blue parts are in our catalog; gray ones we order in.
Tap any part number on the diagram to see what it is, whether we stock it, and add it to your cart.
Need a part that isn’t listed?
Kingston numbers the parts on its diagrams without part numbers. Tap the number on the diagram, or send us the number with your model and finish, and we’ll look it up with Kingston and send a price.
Request a part from this diagramKingston Brass KB1970AX parts questions
Which Kingston Brass models does this Kingston Brass parts diagram cover?
KB1970AX, KB1971AX, KB1972AX, KB1973AX, KB1975AX, KB1976AX, KB1977AX, KB1978AX. They are the same heritage widespread bathroom faucet with plastic pop-up in different finishes, so they share one parts diagram.
What finishes does the Kingston Brass KB1970AX come in?
Matte Black (KB1970AX), Polished Chrome (KB1971AX), Polished Brass (KB1972AX), Antique Brass (KB1973AX), Oil Rubbed Bronze (KB1975AX), Polished Nickel (KB1976AX), Brushed Brass (KB1977AX), Brushed Nickel (KB1978AX).
What replacement handles fit the KB1970AX?
We don't list a matching handle for this model online. Send us the model number and finish and we'll order it from Kingston.
How do I order a part from the KB197xAX diagram?
Kingston numbers the parts on this diagram (54 parts) without part numbers. Tap the number and send it with your model and finish; our counter looks it up with Kingston and sends a price.
Kingston Brass KB197xAX in every finish
Kingston Brass KB1970AX Heritage Widespread Bathroom Faucet with Brass Pop-Up, Matte Black$347.72Matte Black
Kingston Brass KB1971AX Heritage Widespread Bathroom Faucet with Plastic Pop-Up, Polished Chrome$253.47Polished Chrome
Kingston Brass KB1972AX Heritage Widespread Bathroom Faucet with Brass Pop-Up, Polished Brass$337.97Polished Brass
Kingston Brass KB1973AX Heritage Widespread Bathroom Faucet with Brass Pop-Up, Antique Brass$337.97Antique Brass
Kingston Brass KB1975AX Heritage Widespread Bathroom Faucet with Plastic Pop-Up, Oil Rubbed Bronze$318.47Oil Rubbed Bronze
Kingston Brass KB1976AX Heritage Widespread Bathroom Faucet with Brass Pop-Up, Polished Nickel$337.97Polished Nickel
Kingston Brass KB1977AX Heritage Widespread Bathroom Faucet with Brass Pop-Up, Brushed Brass$337.97Brushed Brass
Kingston Brass KB1978AX Heritage Widespread Bathroom Faucet with Plastic Pop-Up, Brushed Nickel$318.47Brushed Nickel
