Belknap AE8100RX exploded diagram
Tap a part number to see the part, its price and fit. Blue parts are in our catalog; gray ones we order in.
Tap any part number on the diagram to see what it is, whether we stock it, and add it to your cart.
Need a part that isn’t listed?
Kingston numbers the parts on its diagrams without part numbers. Tap the number on the diagram, or send us the number with your model and finish, and we’ll look it up with Kingston and send a price.
Request a part from this diagramBelknap AE8100RX parts questions
Which Kingston Brass models does this Belknap parts diagram cover?
AE8100RX, AE8101RX, AE8105RX, AE8106RX, AE8107RX, AE8108RX. They are the same three-handle 2-hole deck mount clawfoot tub faucet with hand shower in different finishes, so they share one parts diagram.
What finishes does the Kingston Brass AE8100RX come in?
Matte Black (AE8100RX), Polished Chrome (AE8101RX), Oil Rubbed Bronze (AE8105RX), Polished Nickel (AE8106RX), Brushed Brass (AE8107RX), Brushed Nickel (AE8108RX).
What replacement handles fit the AE8100RX?
We don't list a matching handle for this model online. Send us the model number and finish and we'll order it from Kingston.
How do I order a part from the AE810xRX diagram?
Kingston numbers the parts on this diagram (25 parts) without part numbers. Tap the number and send it with your model and finish; our counter looks it up with Kingston and sends a price.
Belknap AE810xRX in every finish
Belknap AE8100RX Three-Handle 2-Hole Deck Mount Clawfoot Tub Faucet with Hand Shower, Matte Black$890.47Matte Black
Belknap AE8101RX Three-Handle 2-Hole Deck Mount Clawfoot Tub Faucet with Hand Shower, Polished Chrome$747.47Polished Chrome
Belknap AE8105RX Three-Handle 2-Hole Deck Mount Clawfoot Tub Faucet with Hand Shower, Oil Rubbed Bronze$822.22Oil Rubbed Bronze
Belknap AE8106RX Three-Handle 2-Hole Deck Mount Clawfoot Tub Faucet with Hand Shower, Polished Nickel$890.47Polished Nickel
Belknap AE8107RX Three-Handle 2-Hole Deck Mount Clawfoot Tub Faucet with Hand Shower, Brushed Brass$890.47Brushed Brass
Belknap AE8108RX Three-Handle 2-Hole Deck Mount Clawfoot Tub Faucet with Hand Shower, Brushed Nickel$822.22Brushed Nickel
